Structure-Match Conditioning for Adobe Firefly Video

Diffusion-based text-to-video models give creators a powerful interface for generating videos from text prompts, but they provide limited control over the geometry, layout, and motion of the generated clip. A creator may want the output to follow the structure of a mockup, a hand-drawn sketch, a reference video, or a 3D depth pass, while still using text to control the visual appearance. Standard text-only generation does not provide a direct way to express this structural intent.

This project introduces a modular adapter-based conditioning network that augments a DiT-based text-to-video backbone with structural guidance. In this proof of concept, the structure is represented using per-frame edge and depth maps extracted from a reference clip. The adapter supports any subset of conditioning modalities at inference time, including no conditioning, which recovers the original text-to-video setting. It also handles dense, sparse, and single-frame temporal conditioning using a single trained checkpoint.

A useful property of the design is that each conditioning modality can be controlled continuously at sample time. Edge and depth can therefore act as anything from a weak structural hint to a strong reference constraint. We validate the approach over Adobe's internal production text-to-video model using 20-frame clips at a fixed spatial resolution.

We design the conditioning network as a modular adapter that augments a DiT-based text-to-video backbone. Per-frame edge and depth maps are extracted from a reference clip, encoded into auxiliary streams, and injected into the denoising process through the adapter. The base model remains the text-to-video generator, while the adapter provides an additional pathway for structural control.

Two inputs determine how the conditioning is applied. The first is a per-modality strength scalar, one for edge and one for depth, which controls how strongly each structural stream influences generation. The second is a temporal mask that specifies which video frames contain conditioning signal. During training, both are sampled stochastically: strength values are sampled from a continuous range, and temporal masks are sampled across dense, sparse, and single-frame regimes.

This training strategy makes the checkpoint flexible at inference time. The same model can be used with edge only, depth only, both modalities, or no structure at all. It can also be used with conditioning on every frame, a few anchor frames, or a single anchor frame, without training separate models for each setting.

• Modular structural conditioning: an adapter-based network that augments a DiT-based text-to-video model with edge and depth cues, without modifying the base model architecture.
• Continuous per-modality control: edge and depth guidance can be dialed independently at inference time, ranging from a subtle hint to strong reference adherence.
• Flexible modality usage: the same checkpoint supports pure text-to-video generation, edge-only conditioning, depth-only conditioning, and joint edge-depth conditioning.
• Unified temporal conditioning: a stochastic temporal-masking scheme enables dense, sparse, and single-frame conditioning under one training setup.
• Production-model proof of concept: the method was instantiated over Adobe's internal production text-to-video backbone and fine-tuned for 20-frame video generation at a fixed spatial resolution.

The results below show qualitative samples organized by temporal regime. Each example presents the structural inputs followed by independent samples generated from the same prompt and conditioning signal.

I thank Gunjan Aggarwal and Lakshya for their technical guidance throughout this project, and Kshitij Garg for hosting the work on his team. I am also grateful to the broader Adobe Firefly Video team for the model, infrastructure, and engineering support on which this work was built.
